Photo is representative
Chint NB2LE 1P+N 25A Type B 6kA 30mA Type A RCBO, 1 Module
Product Information
priced individually
Net price: €21.90
Gross price
€26.93
Mon–Fri Free delivery over €61.50
Usually 1–3 working days 28-day returns
On unused items
The Chint NB2LE 1P+N B25 30mA Type A (article 689019) is a residual current circuit breaker with overcurrent protection (RCBO) in a single 18mm module. It combines 25A Type B overload and short-circuit protection (magnetic trip at 3-5 x In) with Type A residual current protection at 30mA, in one device to IEC/EN 61009-1.
Rated breaking capacity is 6kA (Icn 6000A) with a rated residual making and breaking capacity of 3000A, at 230/240V AC, 50/60Hz, and a 4kV impulse withstand. The residual trip time is 0.1s at IΔn, 0.05s at 2IΔn and 0.04s at 5IΔn. The device is supplied from the top, the neutral terminal is on the left, and the terminals are tightened to 1.5Nm. It measures 18 x 95 x 77mm, mounts on 35mm DIN rail and has a test button and red/green contact indication. Electrical life is 4,000 operations and mechanical life 20,000.
