Steinel IS 3360 MX High Bay Motion Detector 4-14m IP54 White

Product Information

Stock Code 033569
GTIN 4007841033569
Stock status: Out of stock

priced individually

Net price: €115.50

Gross price

€142.07

The Steinel IS 3360 MX is a 360° PIR motion detector built for high-bay applications in industrial buildings and commercial properties. Ceiling mounted, it covers large open areas in warehouses and sports halls.

  • Mounting height 4-14m, optimum 12m
  • Detection reach Ø36m tangential (1018m²), Ø14m radial (154m²)
  • IP54 rated, -20°C to 50°C ambient
  • Switching load 2000W resistive, 600W for LED lamps >8W
  • Time delay 5s-15min, twilight setting 2-1000 lx
Specifications

Voltage

220 – 240 V / 50 – 60 Hz

Power Consumption

0.26 W

IP Rating

IP54

Ambient Temperature Range

-20 to 50 °C

Detection Angle

360°

Mounting Height

4.00 – 14.00 m

Reach, Tangential

Ø 36 m (1018 m²)

Reach, Radial

Ø 14 m (154 m²)

Switching Output, Resistive

2000 W

Switching Output, LED Lamps >8W

600 W

Time Setting

5 s – 15 Min.

Twilight Setting

2 – 1000 lx

Dimensions (L x W x H)

65 × 95 × 95 mm
