Photo is representative
Soler & Palau TD-500/150 3V Mixed Flow Inline Duct Fan 150mm 230V Three Speed
Product Information
Stock Code
TD500-150
GTIN
8413893870599
Stock status: 9 available for delivery
priced individually
Net price: €193.80
Gross price
€238.37
Fast dispatch from stock
Mon–Fri Free delivery over €61.50
Typically shipped within 1-2 working days 28-day returns
On unused items
Mon–Fri Free delivery over €61.50
Typically shipped within 1-2 working days 28-day returns
On unused items
Secure checkout
The S&P TD-500⁄150 3V is a low-profile in-line mixed-flow duct fan from the TD-MIXVENT series, for 150mm ducting. The casing is reinforced plastic (polypropylene) with an ABS impeller. The support bracket lets the motor and impeller be removed without dismantling the adjacent ducting. It can be mounted at any point along the duct.
The motor is a three-speed, direct-connection motor and can also be voltage speed controlled. It has ball bearings greased for life and a manual-reset thermal protector (PTC).
- Airflow (free discharge): 560 / 470 / 390 m³/h (high / medium / low)
- Sound pressure (3m, free field): 35 / 31 / 26 dB(A)
- Power / current: 53W, 0.21A / 44W, 0.19A / 41W, 0.18A
- Speed: 2590 / 2150 / 1820 rpm
- Supply: 230V 50/60Hz single phase
- Protection: IP44, Class II
- Dimensions: 295mm long, Ø200mm casing, Ø147mm spigots (150mm duct), 212mm high incl. terminal box
- Weight: 2.7 kg
