Photo is representative
Plastim ABS Enclosure 500x400x175mm IP65 Grey Door with Mounting Plate PP3003
Product Information
priced individually
Net price: €79.64
Gross price
€97.96
Mon–Fri Free delivery over €61.50
Usually 1–3 working days 28-day returns
On unused items
The Plastim PP3003 is a wall-mounted plastic enclosure from the grey-door range, measuring 500 x 400 x 175mm (H x W x D) and weighing 4.3kg. The body and door are moulded in HB ABS in RAL 7035 grey, and the door is sealed with a polyurethane gasket to give IP65 protection against dust and water jets. Impact protection is IK08.
A 1mm galvanised steel mounting plate is supplied for fitting DIN rail, terminals and control components. Plastim state resistance to chemical agents, alkalis, oils and salts, an operating temperature range of -35°C to +65°C and a rated voltage of up to 690V. The range is CE marked and RoHS compliant. For the same 500 x 400mm face in a deeper 240mm body, see the PP3007.
