Elkat fork busbar 4P 63A 18mm pitch 1m

Photo is representative

Elkat fork busbar 4P 63A 18mm pitch 1m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code IZ104F56
GTIN —
Stock status: Available for delivery

priced individually

Net price: €53.10

Gross price

€65.31

Branch Stock

Monaghan

Store with product available for collection.

Stock status: Out of stock
Opening hours

Store Information

Address:

Monaghan, Plantation Road, Co. Monaghan, H18 E781, Ireland
Phone: +353 47 81135

Opening hours:

Monday - Thursday
8:00 AM - 6:00 PM
Friday
8:00 AM - 5:00 PM
Saturday
9:00 AM - 1:00 PM
Sunday
Closed

Carrickmacross

Store with product available for collection.

Stock status: 8 in stock
Opening hours

Store Information

Address:

Carrickmacross, Ardee Rd, Co. Monaghan, A81 Y573, Ireland
Phone: +353 42 9663322

Opening hours:

Monday - Thursday
8:00 AM - 6:00 PM
Friday
8:00 AM - 5:00 PM
Saturday
9:00 AM - 1:00 PM
Sunday
Closed

Cavan

Store with product available for collection.

Stock status: 4 in stock
Opening hours

Store Information

Address:

Cavan, Unit 7, Kilmore Business Park, Dublin Road, Co. CavanH12 PV48, Ireland
Phone: +353 49 4365190

Opening hours:

Monday - Thursday
8:00 AM - 6:00 PM
Friday
8:00 AM - 5:00 PM
Saturday
9:00 AM - 1:00 PM
Sunday
Closed
Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 28 day returns

4P insulated fork comb busbar from Elkat. Covers L1, L2, L3 and N across 56 modules at 18mm pitch — 1000mm overall length. 10mm² ETP copper bar (CW004A, 99.9% purity), PVC insulated in RAL 7035 grey.

Suited to modular MCB and RCBO installations where a fork-type connection is required.

  • 63A current rating, 500V insulation voltage
  • 4kV impulse withstand (Uimp)
  • Conforms to IEC 60947-1 and IEC 60947-7-1
Specifications

Poles

4P (L1-L2-L3-N)

Current Rating (Ie)

63 A

Nominal Voltage (Ue)

240/415 V

Rated Insulation Voltage (Ui)

500 V

Impulse Withstand Voltage (Uimp)

4 kV

Cross-Section

10 mm²

Pitch

18 mm

Modules

56

Length

1000 mm

Conductor Material

99.9% ETP Copper CW004A

Insulation Material

PVC

Insulation Colour

RAL 7035 Grey

Standards

IEC 60947-1, IEC 60947-7-1
