Photo is representative
ABB Tmax XT1N 160 MCCB 100A 4 Pole TMD, 36kA, Front Terminals, Fixed
Product Information
priced individually
Net price: €226.88
Gross price
€279.06
Mon–Fri Free delivery over €61.50
Usually 1–3 working days 28-day returns
On unused items
This is the ABB SACE Tmax XT1N 160 moulded case circuit breaker in its 4-pole fixed version with front terminals, fitted with a TMD thermomagnetic release rated In 100 A. The XT1 160 frame has a rated uninterrupted current Iu of 160 A; this unit is the 100 A rating, with a thermal setting range of 70 to 100 A and a magnetic trip at 1000 A. The N breaking capacity gives Icu 36 kA and Ics 36 kA at 380 to 415 V AC, and Icu 65 kA at 220 to 240 V AC. Rated operational voltage Ue is 690 V AC and 500 V DC, with insulation voltage Ui 800 V and impulse withstand Uimp 8 kV. Connections are front M6 bolt terminals. The breaker measures 101.6 x 130 x 70 mm and weighs 1.4 kg. ABB order code 1SDA067424R1.
